AX1800 Wi-Fi 6 беспроводной адаптер, порт подключения USB 3.2
EW-7822UMX
  • AX1800 Wi-Fi 6 Сверхскоростной : Max. data transfer rate up to 1201Mbps (5GHz) and 573Mbps (2.4GHz)
  • High Performance 802.11ax Technology: Supports OFDMA and MU-MIMO allowing greater Wi-Fi efficiency
  • Secure Wi-Fi: High level Wi-Fi security supported with WPA3-SAE (Personal), 802.1x, WEP, WPA TKIP and WPA2 AES/Mixed mode for PSK & TLS
  • Easy Installation: Simple and quick 3-step installation via a USB 3.0 port
  • Instant Upgrade to Wi-Fi 6: Simply and quickly adds Wi-Fi 6 to your PC and laptop via USB port
  • Wide Compatibility: Works with any Wi-Fi router/AP/extender and backward compliant with 802.11a/b/g/n/ac standards
  • Supports Windows 10 and Linux OS
  • Excellent for gaming, HD video, high quality music and large file transfers

Share


Play with Blazing Speed | Wi-Fi 6

Enjoy ultra-speed for your home entertainments

More Efficiency, Less Latency

1.5X Faster Speed

More stable and smoother streaming than ever before. No more queuing up forever.

EDIMAX EW-7822UMX AX1800 Wi-Fi 6 USB 3.0 Adapter, OFDMA

OFDMA Supported

With Wi-Fi 6 OFDMA technology, EW-7822UMX allows many low-bandwidth streams to transmit in parallel, reducing latency and jitter. Reduced latency for the terminal device is an important requirement for IoT and video that the 802.11ax can now address.

EDIMAX EW-7822UMX AX1800 Wi-Fi 6 USB 3.0 Adapter, OFDMA

MU-MIMO Supported

EDIMAX EW-7822UMX supports MU-MIMO, it’s a multiuser technology that increases capacity, facilitates higher speeds, and is ideal for applications that require high bandwidth. Users can enjoy improved Wi-Fi performance when connected to an MU-MIMO enabled network.

WPA3 High-Level Security

By using a 128-bit encryption key, the new WPA3 security can protect user passwords from attacks and more. As a result, it’s safer, and you will never screw up in risks.

USB 3.1 Truly Realize 11AX Speed

USB 3.0 works up to 10 times faster than USB 2.0, with data transfer rates up to 5Gbps that enables the EW-7822UMX to achieve superfast speeds provided by the 802.11ax – for faster photos, music, videos, and data transfers with your computer.

Instant Upgrade, Wi-Fi 6 On-The-Go

With quick and simple installation, the EW-7822UMX USB adapter is the best choice for your laptop or PC and get an instant upgrade to Wi-Fi 6. It's portable in design, so you can take it with you anywhere for a fast Wi-Fi connection.

Backward Compliant, Works with all Wi-Fi

Backward compliant with 802.11a/b/g/n/ac standards, the EW-7822UMX supports all existing Wi-Fi 6/5/4 routers, access points and range extenders. It is the best choice for your laptop or PC.

Share


Технические характеристики

Аппаратное обеспечение ​
Интерфейс 1 x USB 3.2 Type A
Светодиоды 1 x Link/Activity LED
Aнтенны 2 x Internal PIFA Antenna (2T2R)
Размеры 103.6(L) x 30.1(W) x 15(H) mm (4.08(L) x 1.19(W) x 0.59(H) inches)
Вес 25g (0.88 ounces)
Беспроводное
Стандарты
  • 2.4GHz: IEEE 802.11b, 802.11g, 802.11n
  • 5GHz: IEEE 802.11ax, 802.11ac, 802.11a, 802.11n
Рабочие частоты
  • 2.4GHz: 2.412~2.472ГГц
  • 5GHz: 5.180 ~5.240; 5.260~5.320ГГц
*Subject to local regulations.
Скорость
  • 11a: Up to 54Mbps
  • 11b: Up to 11Mbps
  • 11g: Up to 54Mbps
  • 11n: Up to 400Mbps
  • 11ac: Up to 867Mbps
  • 11ax (2.4GHz): Up to 574Mbps
  • 11ax (5GHz): Up to 1201Mbps
Выходная мощность 2.4GHz:
  • 11b(11M): 18±1.5dBm
  • 11g(54M): 15±1.5dBm
  • 11n(20MHz, MCS7): 13±1.5dBm
  • 11n(40MHz, MCS7): 13±1.5dBm
5GHz:
  • 11a(54M): 15±1.5dBm
  • 11n(20MHz, MCS7): 13±1.5dBm
  • 11n(40MHz, MCS7): 13±1.5dBm
  • 11ac(80MHz, VHTMCS9): 12±1.5dBm
Чувствительность приемника 2.4GHz:
  • 11b(11M): -80±2dBm
  • 11g(54M): -68±2dBm
  • 11n(20MHz, MCS7): -66±2dBm
  • 11n(40MHz, MCS7): -65±2dBm

​5GHz:
  • 11a(54M): -68±2dBm
  • 11n(20MHz, MCS7): -65±2dBm
  • 11n(40MHz, MCS7): -62±2dBm
  • 11ac(80MHz, VHTMCS9): -52±2dBm
Безопасность
  • WPA3-SAE (Personal), 802.1x, WEP, WPA TKIP and WPA2 AES/Mixed mode for PSK & TLS
  • Software WPS (Wi-Fi Protected Setup)
OTHERS
Системные требование
  • Windows 10
  • Linux: Kernel 3.13 - 5.9 (support Fedora & Ubuntu only)
*Additional version information will be announced on the EDIMAX website.
Рабочая среда Temperature:
  • Operating Temperature: 0~40°C (32~104°F)
  • Storage Temperature: -20~65°C (-4~149°F)
Humidity:
  • Operating Humidity: 10~90% (Non-condensing)
  • Storage Humidity: 10~90% (Non-condensing)
Сертификаты CE, FCC,BSMI,NCC, EAC
*Максимальная производительность, реальная скорость и покрытие сети зависят от условий окружения.
*Спецификации продукта и его дизайн могут быть изменены без предварительного уведомления.
